3.25 Lac - 8.55 Lac / Piece
| Business Type | Manufacturer, Supplier |
| Model | CL1390, CL1325, CL1410 |
| Laser Type | Co2 |
| Head Type | Single head or Dual head |
| Click to view more | |
Preferred Buyer From
| Location | Anywhere in India |
Product Details
Working Area
1300mm*900mm / 1300*2500mm / 1400*1000mm
Laser Power
100W/130W/150W
Laser Source
Sealed Glass Co2 Laser Tube (Reci/Yongli/EFR)
Application
Laser Cutting & Engraving of Soft Wood and Other All Nonmetal Materials
Application Material
Wood, Acrylic, MDF, Leather, Cloth, Rubber, Plastic, Fabric, Paper, Plywood
Machine Body
Mild Steel (High Strength Metallic)
X Y Axis System
Belt (Imported) or Gear Box
Z Axis System
Manual
Guide System
X Axis = Inside Y = Outside
Co2 Glass Tube
Yongli or Reci or EFR
Working Table
Honey Comb or Knife Strip
Controller
Ruida RD 6445S (EC) (New model)
Cooling Mode
Water Chiller (S & A 5200 CW Series)
Blower (Air Exhaust)
550 Watt
Power Supply
ZYE Power Supply (Display Screen, Yongli)
Air Compressor
135 Watt
Operating System
Windows 7 32 bit/64 bit/windows 10
Interface System
USB Interface
Driving System
Stepper Motor
Add. Feature Accessories
S&A Chiller CW5200 TG, Hailea Air Compressor ACO-009D 135W, Exhaust Fan 550W, Tool Box
Warranty
Full Machine 1 Year, Laser Tube 6 Month
Brand Name
Creative Laser
Country of Origin
India
Supported File Format
PLT, DXF, BMP, JPG, GIF, PNG
Max Cutting Thickness
12 mm Acrylic, 8 mm MDF
Min Letter Cutting
1 mm (English Font)
Running Environment
45 Degree C; Humidity 5%-95% (without condensed water)
Working Voltage
Single Phase AC220V±10%, 50-60Hz (Required Earthing)
Weight
350-400 Kg / 750-800 Kg (depend on model)
Cutting Speed
500-600mm/sec
Engraving Speed
800-1000mm/sec
Working Speed
600mm/sec
Travelling Speed
<500mm/sec
Power Consumption
2 – 3 Unit / Hours
Power Adjustment
1 to 100%
Reposition Accuracy
+0.01mm
Packaging Details
High Strength Wooden Box
